The M1 is a new tube microphone. A whole new circuit design inspired by the vintage greats. Designed by Andrew Myburgh, Andreas Grosser and Eckehard Dux.

​

M1 + Latch Lake deal can be ordered HERE.

MYBURGH - M1


capsule & tube

The M1 incorporates a German made Mylar M7 capsule manufactured by Siegfried Thiersch and a Russian military grade long life tube.

amplifier &
transformers

The M1’s amplifier has an incredible linear frequency response with minimal cut off below 30Hz or over 20kHz. With two custom built transformers; one in the mic and another in the power supply, the amplifier design, combined with the German made capsule and the new capsule headbasket design give the M1 its unique sound.


noise floor,
output & SPL

The M1 also has a super low noise floor, a monster output and handles SPL like your favourite FET kick drum mic does. Variable polar patterns and true cardioid is a main feature.

specifications

circuit design
Original all new circuit design

​

polar pattern
Variable on detented potentiometer:
Omni; Cardioid; Figure 8 plus 100% Cardioid selectable on PSU

​

frequency response
20 Hz - 20 kHz

​

internal
pre-amplification stage
Linear 30 Hz - 20 kHz

sensitivity

24mV/Pa

​

equivalent noise level

15dBA

​

maximum SPL

124 dB

​

capsule

M7 Thiersch Mylar

​

tube

Russian Military Grade Tube

transformers

Custom specifications. M1 and PSU transformers by Pikatron

​

cable

Mogami Neglex 3172 tube microphonecable 7m (23 ft)

​

connectors

7 Pin = Binder and 3 pin XLR = Neutrik

​

output impedance

200 Ω

​

dimensions

M1 22.5cm (8.85”) /  M1
+ Swivel = 35.5cm (14”)

​

weight

M1 = 0.6 kg (1.3 lbs) / M1
+ Swivel = 1.9 kg (4.2 lbs)

​

shipping weight

9 kg (20 lbs)

​

peripherals

Custom M1 box
Waterproof Case
Swivel pouch

​

Specifications

unprecedented
build quality

Largely made of brass, the M1’s build quality is unprecedented. All metalwork is custom designed and manufactured. The mechanical lifespan of the M1 is intended to last far beyond the typical modern day microphone. Built to last a few lifetimes infact.

Testimonials

"While reminiscent of the vintage greats, the M1 brings its own flavour. Its flexible pattern choice, high SPL handling and the unique True Cardioid sets it apart from anything else on the new and vintage market."

GUY STERNBERG
producer | mixer | engineer

GERMANY


"What's better than an M1? Two M1's! One of the greatest mics around, the Myburgh M1. Still blows my mind how great a mic this is. A new classic."

'EVIL' JOE BARRESI

producer | mixer | engineer

USA


“I sang all the vocals on the album on this beautiful thing. Chose it over a Neumann u47, u67 and m49. All in pristine condition. Absolutely amazing mic.”

ALON LOTINGER

producer | mixer | engineer

ISRAEL

listein booth3.jpg

benchmarking the vintage greats

Through our development phase we benchmarked extremely well maintained original U47 and U67 microphones. These microphones were also used for the recording of our comparison files.

only available from


if your country or territory is not listed please contact us directly
